Axial Fan Motor 230V 40-700W for Condensers and Evaporators
The axial fan moves the air axially as the axial fan impellers are made of sheet metal and are welded on to the external rotor motor directly. Axial fans use a propeller and generate airflow in the direction of the axis of rotation as the large airflow of axial fans is suitable for ventilation and cooling inside because it moves the air axially and parallels to the revolving motor shaft.
- Stable Running
- Low Noise
- High Efficiency
Condenser Fan Motor Refrigerator Fridge
Condenser Motor Fridge Freezer Fan Motor 1300/1500 RPM
Danfoss FR6G 1/6HP Compressor
Danfoss FR6G 1/6HP Compressor
| Type | Capacity LBP -25/55°C (W) | Capacity HBP +5/55°C (W) | Test Conditions |
|---|---|---|---|
| T | 40 | 20 – 230 | EN 12900/CECOMAF |
| N | 130 – 200 | 570 – 1090 | EN 12900/CECOMAF |
| F | 90 – 150 | 600 | EN 12900/CECOMAF |
| S | 490 – 270 | 850 – 1500 | EN 12900/CECOMAF |
Notes
- LBP (Low Back Pressure): -25/55°C
- HBP (High Back Pressure): +5/55°C
- Refrigerant: R134a
- Voltage: 220-240V/60H
Danfoss FR8.5G 1/4HP R404c Compressor
| Type | Capacity LBP -25/55°C (W) | Capacity HBP +5/55°C (W) | Test Conditions |
|---|---|---|---|
| T | 40 | 20 – 230 | EN 12900/CECOMAF |
| N | 130 – 200 | 570 – 1090 | EN 12900/CECOMAF |
| F | 90 – 150 | 600 | EN 12900/CECOMAF |
| S | 490 – 270 | 850 – 1500 | EN 12900/CECOMAF |
R404A/R507, 220-240V/50Hz
| Type | Capacity HBP +5/45°C (W) | Test Conditions |
|---|---|---|
| F | 840 | EN 12900/CECOMAF |
| G | 3211 – 5060 | EN 12900/CECOMAF |
| N | 945 – 1125 | EN 12900/CECOMAF |
| S | 1450 – 4420 | EN 12900/CECOMAF |
| T | 527 | EN 12900/CECOMAF |
Danfoss SC12G 1/3HP Compressor
Danfoss SC18G 3/4HP Standard Compressor
Danfoss SC18G 3/4HP Standard Compressor
Danfoss SC18G Standard Compressor
- Application LBP / MBP
- Refrigerant: R134a
- Displacement: 17.69 cc
- Power: 5/8 HP
- Motor size watt 495
- Voltage 220-240V 50Hz
- Expansion = Capillary tube or expansion valve
Danfoss SC21G 1HP Compressor R134a
Danfoss SC21G 1HP Compressor R134a
Compressor Danfoss SC21G 1HP| Specification | Details |
|---|---|
| Model | SC21G |
| Refrigerant Gas | R-134a |
| Pressure/Temperature | MHBP |
| Power | 5/8 HP |
| Voltage | 230 V |
| Current Type | Single-Phase |
| Frequency | 50/60 Hz |
| Compressor Type | Hermetic |
| Displacement | 20.95 cm³ |
| Power Consumption -25°C | 382 W |
| Power Consumption -10°C | 575 W |
| Power Consumption -5°C | 643 W |
| Efficiency at 0°C | 714 W |
| Power Consumption +5°C | 789 W |
| Power Consumption +7.2°C | 823 W |
| T° Condensation | 55 °C |
| SC21G | 220V-240VÂ 50Hz | 5/8HP | 469 | R134a | Low/High |
